ESP (Electrostatic Precipitator): A device used in ventilation systems to remove particles from the air by applying an electrical charge, improving air quality.
IESP (Intelligent Electrostatic Precipitator): An advanced version of ESP that uses sensors and smart technology to optimize particle removal and energy efficiency in ventilation systems.
| Specification | Details |
|---|---|
| Product | ESP & IESP (Electrostatic Precipitators) |
| Dimensions/Weight | H: 540 x W: 1790 x L: 620 mm / 122 kg |
| Cabinet Material | Galvanized Steel, 1.4 mm / 16 Gauge |
| Finishing | Powder Coated, Dark Blue |
| Air Volume (Rated-Max) CFM: | 4500-6100, CMH: 7500-10,500; L/s: 2100-2900 |
| Static Pressure | 50 pa / 0.2″ |
| Voltage & Power | 230 VAC +/-10%, 50/60Hz, 105 Watts |
| lonising Voltages | High Voltage: 12KVdc. Low Voltage: 6KVdc |
| Air Flow Direction | Default: Right to Left; Reversible: Left to Right |
| Power Supply | High Frequency solid state and self-regulating design |
| Particle Size | From 0.01 microns – 10 microns |
| Efficiency | DOP Test: Up to 95% single pass, up to 99% double pass (calculated) ASHRAE 52.2-2012: Up to 96% single pass, up to 99% double pass(calculated) NIOSH 5026 Oil Mist Field Test: Up to 96% |
| MERV Ratings | Meets MERV 15 at velocity of 2.5 m/s to 3.8 m/s |
| Pre-Filter | Aluminum wire mesh, Washable x 3 |
| Electrostatic Cell Dimensions | H: 472 mm, W: 550 mm, L: 340 mm |
| Number of Cells / Weight | 3 Cells / 16.5 kg |
| Number of Plates per Cell | 59 |
| Total Collecting Area | 18.21 m2 |
| Post Filter (Optional) | Aluminum wire mesh, Washable x 3 |
| Installation | Ceiling Suspended; Wall or Frame Mounted, Multiple |
